RK100-06 Pipe Wind Pressure Sensor

CE-EMC, CE-LVD, RoHS, ISO9001

Description

RK100-06 shell is made of flame retardant and corrosion-resistant material. Based on the principle of pitot tube pressure measurement, the gas required for measurement is very little. The performance of RK100-06 shell is equally reliable even in harsh environment with a small amount of dust. The product can obtain higher reliability and repeatability by using digital linear compensation and temperature compensation.

Specification

Item Specification
Range 0-100Pa,0-250Pa,0-500Pa,0-1000Pa,0-2000Pa,0-5000Pa,0-10000Pa
Supply 24VDC
Output 4-20mA,0-10V,RS485
Response time <1s
Accuracy ±1%FS
Resolution 1Pa
Power consumption     <40mA@24VDC(4-20mA) <20mA@24VDC(RS485,0-10V)
Display LCD optional
Ingress Protection IP65
Operating Temperature -20℃-+70℃
Main material Flame retardant ABS
Probe length 220mm typ., Other length(<1500mm) can be customized
Storage condition 10℃-60℃@20%-90%RH

Dimension & Mounting
